SOLENOID VALVE 4V SERIES THREE-POSITION จำนวนผู้เข้าชม: 0 ครั้ง

- รหัสสินค้า:4V
- ชื่อสินค้า:
  SOLENOID VALVE 4V SERIES THREE-POSITION
- หมวดสินค้า:Solenoid Valves

คุณสมบัติ,รายละเอียดอื่นๆ: SOLENOID VALVE 4V SERIES THREE-POSITION

Type	Port size	Effective area	Temperature	CV Value	Power consumption	Position&coil	operating pressure	Valtage
4V110-M5	M5	12mm²	-5-50°C	0.56	3VA	5/2 way Internally piloted acting type Double electrical control midst pressure type	0-9/kgf/cm²	DC12V DC24V DC48V AC24V AC36V AC110V AC220V
4V110-06	PT1/8	16mm²	-5-50°C	0.78	3VA
4V210-06	PT1/8	30mm²	-5-50°C	1.40	3VA
4V210-08	PT1/4	50mm²	-5-50°C	2.80	3VA
4V310-08	PT1/4	14mm²	-5-50°C	0.56	3VA	5/2 way Internally piloted acting type Double electrical control midst pressure type
4V310-10	PT3/8	14mm²	-5-50°C	0.78	3VA
4V410-10	PT3/8	25mm²	-5-50°C	1.40	3VA
4V410-15	PT1/2	50mm²	-5-50°C	2.80	3VA
4V120-06	PT1/8	7mm²	-5-50°C	0.67	3VA	5/3 way Internally piloted acting type Double electrical control midst pressure type
4V220-06	PT1/8	12mm²	-5-50°C	0.78	3VA
4V220-08	PT1/4	18mm²	-5-50°C	1.68	3VA
4V320-10	PT3/8	30mm²	-5-50°C	1.68	3VA
4V420-15	PT1/2	7mm²	-5-50°C	0.67	3VA	5/3 way Internally piloted acting type Double electrical control midst pressure type
4V130C-06	PT1/8	12mm²	-5-50°C	0.78	3VA
4V230C-06	PT1/8	18mm²	-5-50°C	1.68	3VA
4V230C-08	PT1/4	30mm²	-5-50°C	1.68	3VA
4V330C-08	PT1/4	7mm²	-5-50°C	0.67	3VA	5/3 way Internally piloted acting type Double electrical control midst pressure type
4V330C-10	PT3/8	12mm²	-5-50°C	0.78	3VA
4V430C-15	PT1/2	18mm²	-5-50°C	1.68	3VA
4V130E-06	PT1/8	30mm²	-5-50°C	1.68	3VA
4V230E-08	PT1/4	7mm²	-5-50°C	0.56	3VA
4V330E-10	PT3/8	12mm²	-5-50°C	0.78	3VA
4V430E-15	PT1/2	18mm²	-5-50°C	1.40	3VA
